Optimization of a Non-Invasive Solar Desalination Prototype Using a Hybrid Desalination System (PV-TE) for Off-Grid Clean Water Production in the Region

Roy Lamrun Sianturi; Rinaldo  Hasudungan Malau; Tiara Melinda

doi:10.17524/ijesmi.v1i2.15

Authors

Roy Lamrun Sianturi Universitas Negeri Medan https://orcid.org/0009-0008-6185-9990
Rinaldo Hasudungan Malau Universitas Negeri Medan
Tiara Melinda Universitas Negeri Medan

DOI:

https://doi.org/10.17524/ijesmi.v1i2.15

Keywords:

Hybrid Desalination, PV-TE, Solar Energy, Off-grid, Clean Water, Coastal

Abstract

Access to clean water in Indonesia's remote coastal areas requires a self-sufficient and sustainable desalination solution. This study aims to optimize a prototype of a non-invasive solar desalination system by integrating Photovoltaic-Thermoelectric (PV-TE) hybrid technology for off-grid clean water production. A pilot-scale unit was developed from a basic passive solar distillation prototype through the addition of photovoltaic panels and thermoelectric modules that double as waste heat recoverers and active condenser coolers. Test results show significant performance improvements, with conductivity removal efficiency reaching 99.83% with ultra-pure water quality (80 µS/cm). Water productivity increased exponentially by 1148%, from 0.50 L/day.m² in the basic prototype to 6.24 L/day.m² in the hybrid system, with a system energy conversion efficiency reaching 29.05%. These findings confirm that the strategic integration of PV-TE components not only overcomes productivity limitations in passive solar desalination but also offers an autonomous desalination solution with low environmental impact. This research contributes to the development of self-sufficient water infrastructure that can be replicated in coastal communities with abundant solar intensity.

Downloads

Download data is not yet available.

References

[1] APE kowati and MFD Lusno, “Analysis of Achievements and Challenges of Access to Safe Drinking Water in Indonesia Towards SDGS 6.1. 1,” J. Penelit. Inov., vol. 5, no. 2, pp. 1707–1714, 2025.

[2] BPS Indonesia, "Percentage of Households Having Access to Improved Drinking Water Sources by Province - Statistical Table.” Accessed: Feb. 06, 2026. [Online]. Available: https://www.bps.go.id/id/statistics-table/2/ODQ1IzI=/percentage-of-households-having-access-to-safe-drinking-water-sources-by-province.html

[3] RDLufira, U. Andawayanti, and NZ ST Fitriani, Water Resources Crisis: Innovative Approaches and Sustainable Solutions. CV. AE MEDIA GRAFIKA, 2025.

[4] E. Jones, M. Qadir, MT Van Vliet, V.Smakhtin, and S. Kang, “The state of desalination and brine production: A global outlook,” Sci. Total Environ., vol. 657, pp. 1343–1356, 2019.

[5] M. Goosen, H. Mahmoudi, Y. Alyousef, and N.Ghaffour, “Solar desalination: A review of recent developments in environmental, regulatory and economic issues,” Sol. Compass, vol. 5, p. 100034, Mar. 2023, doi: 10.1016/j.solcom.2023.100034.

[6] G. Hasaninet al., “The microbial growth potential of antiscalants used in seawater desalination,” Water Res., vol. 233, p. 119802, Apr. 2023, doi: 10.1016/j.watres.2023.119802.

[7] HG Hameed, HANDiabil, and MA Al-Moussawi, “A numerical investigation of the enhancement of single-slope single-basin solar still productivity,” Energy Rep., vol. 9, pp. 484–500, Dec. 2023, doi: 10.1016/j.egyr.2022.11.199.

[8] RL Sianturi and WS Nababan, "Hybrid Energy (Thermoelectric Generator-Archimedes Screw Turbine) Study and Experiment as a Green Energy Generator Based on the Internet of Things (IoT),"J. Mech. Eng. Manuf. Mater. ENERGY, vol. 8, no. 2, pp. 147–156, 2024.

[9] AS Abdullah, WHAlawee, SA Mohammed, A. Majdi, ZM Omara, and FA Essa, “Increasing the productivity of modified cords pyramid solar still using electric heater and various wick materials,” Process Saf. Environ. Prot., vol. 169, pp. 169–176, Jan. 2023, doi: 10.1016/j.psep.2022.11.016.

[10] A. Negi, GS Dhindsa, and SS Sehgal, "Experimental investigation on single basin tilted wick solar still integrated with flat plate collector,"SCPINM-2021, vol. 48, pp. 1439–1446, Jan. 2022, doi: 10.1016/j.matpr.2021.09.210.

[11] U. Habitat, “World cities report: Envisaging the future of cities,”UN Hum. Settl. UN-Habitat Nairobi Kenya Programme, 2022.

[12] AS Isah, HBTakaijudin, BS Mahinder Singh, UA Abubakar, SJ Mohammad, and T. Oladoyin abimbola, “Assessing the performance, sustainability, and economic viability of a photovoltaic-based solar desalination system for water scarce regions,” J. Clean. Prod., vol. 421, p. 138528, Oct. 2023, doi: 10.1016/j.jclepro.2023.138528.
